MEAN WELL

A302-300-B2

Name: A302-300-B2
Brand: MEAN WELL
Price: 98.78 USD
Availability: OutOfStock

Manufacturer Model Name

Availability: Out of stock

ℹ️ Lead time for quantities greater than shown, contact us

Quantity Prices

Quantity

Unit Price

$98.78

10+

$93.84

20+

$91.87

50+

$89.89

100+

$87.91

200+

$85.94

*Import tariff is included in the listed price. You pay exactly what you see—no surprise fees at checkout. Discounts are applied automatically based on the total quantity added to your cart.

Quick Specs

Output Voltage

110V

Power Rating

300W

Waterproof

Non-waterproof

Dimensions

6.49 x 3.46 x 2.91 in

Weight

2.42 lbs

Características

Entrada de 12V o 24V DC

Interruptor de encendido/apagado

Rango de tensión de entrada: -15% ~ +25%

Regulación de tensión de salida ±10%

Protecciones: Inversión de polaridad de entrada/Apagado por batería baja/Sobretensión/Sobrecarga/Sobretemperatura/Cortocircuito de salida

Forma de onda de salida: Onda sinusoidal modificada

Control de encendido/apagado del ventilador de refrigeración

Topología: Microprocesador

Aprobaciones: E13 / EAC / CE / UKCA

1 año de garantía

Especificación general

Rango de tensión de salida AC	110V
Forma de onda de salida AC	Onda sinusoidal modificada
Temperatura de sobrecarga	45±5°C/ 113±9°F
Sobretensión	125~142% de carga
Cortocircuito de salida	Apagado
Temperatura de funcionamiento	0 ~ 30°C@ 100% de carga, 40°C@ 50% de carga
Normas de seguridad	Aprobado por EAC TP TC 004
Normas EMC	IEC61000-4-2,3, EAC TP TC 020
Dimensiones (LxAxH)	1658874mm
Embalaje	16 piezas / 19 kg
