MEAN WELL

SPB09C-24

Name: SPB09C-24
Brand: MEAN WELL
Price: 18.09 USD
Availability: OutOfStock

Manufacturer Model Name

Availability: Out of stock

ℹ️ Lead time for quantities greater than shown, contact us

Quantity Prices

Quantity

Unit Price

$18.09

10+

$17.19

20+

$16.82

50+

$16.46

100+

$16.10

200+

$15.74

*Import tariff is included in the listed price. You pay exactly what you see—no surprise fees at checkout. Discounts are applied automatically based on the total quantity added to your cart.

Quick Specs

Output Voltage

24V

Rated Current

0.37A

Power Rating

Waterproof

Non-waterproof

Dimensions

0.98 x 0.44 x 0.37 in

Weight

0.01 lbs

Características

Paquete SIP8 con asignación de pines estándar de la industria

Amplio rango de entrada de 2:1

Amplio rango de temperatura de funcionamiento de -40 a +90°C

No requiere carga mínima

Alta eficiencia de hasta 89%

Protección: Cortocircuito (continuo)/Sobrecarga/Bajo voltaje de entrada

Aislamiento E/S de 1.5KVCC

Control ON/OFF remoto

Modelo de 9V disponible (opcional)

3 años de garantía

Especificación general

Precisión de voltaje	±1.5%
Vibración	10 ~ 500Hz, 2G 10min./1 ciclo, el período para 60min. cada uno a lo largo de los ejes X, Y y Z
Refrigeración	Convección por aire libre
Protección contra cortocircuitos	Continua, recuperación automática
Temperatura de trabajo	-40°C a +90°C
CEM	Conformidad con EN55032 Clase A, EN61000-4-2,3,4,5,6,8
Coeficiente de temperatura	0.03% / ℃ (0 ~ 70℃)
Dimensiones (LxAnxAl) (mm)	249.611.2mm
Material de encapsulado	Clasificación UL 94V-0

Environmental Documents

📄 E6) COC-REACH (2026/01/28) 📄 E9) CMRT (2025/04/25) 📄 E14) COC-ROHS 2 (2015/863/EU) (2024/10/04) 📄 REACH Certificate (PDF) (2020/12/03) 📄 ROHS Certificate (PDF) (2020/05/29) 📄 E12) COC-ROHS 2 (2011/65/EU) (2016/10/01)
