MEAN WELL

SPBW03F-12

Name: SPBW03F-12
Brand: MEAN WELL
Price: 10.24 USD
Availability: OutOfStock

Manufacturer Model Name

Availability: Out of stock

ℹ️ Lead time for quantities greater than shown, contact us

Quantity Prices

Quantity

Unit Price

$10.24

10+

$9.73

20+

$9.52

50+

$9.32

100+

$9.11

200+

$8.91

*Import tariff is included in the listed price. You pay exactly what you see—no surprise fees at checkout. Discounts are applied automatically based on the total quantity added to your cart.

Quick Specs

Output Voltage

12V

Rated Current

0.25A

Power Rating

Waterproof

Non-waterproof

Dimensions

0.85 x 0.43 x 0.36 in

Weight

0.01 lbs

Características

Paquete SIP8 con configuración de pines estándar de la industria

Amplio rango de temperatura de funcionamiento de -40~+85°C

Alta eficiencia de hasta el 85%

Amplio rango de entrada 4:1

No requiere carga mínima

Cumple con BS EN/EN55032 radiado Clase B sin componentes adicionales

Protección: Cortocircuito (continuo)/Sobrecarga/Subtensión de entrada

Aislamiento E/S de 1.5KVDC

Control remoto ON/OFF

Modelo de 9V disponible (opcional)

3 años de garantía

Especificaciones generales

Precisión de voltaje	±1.5%
Vibración	10~500Hz, 2G 10min./1 ciclo, el período durante 60 min, cada uno a lo largo de los ejes X, Y y Z
Refrigeración	Convección por aire libre
Protección contra cortocircuitos	Continua, recuperación automática
Temperatura de trabajo	-40°C a +85°C
EMC	Cumple con EN55032 Clase A, EN61000-4-2,3,4,5,6,8
Coef. de temperatura	0.03% / ℃ (0 ~ 85℃)
Dimensiones (LxAnxAl) (mm)	21.89.211.1mm
Material de encapsulado	Clasificación UL 94V-0

Environmental Documents

📄 E6) COC-REACH (2026/01/28) 📄 E9) CMRT (2025/04/25) 📄 E14) COC-ROHS 2 (2015/863/EU) (2024/10/04) 📄 REACH Certificate (PDF) (2020/12/03) 📄 ROHS Certificate (PDF) (2020/05/29) 📄 E12) COC-ROHS 2 (2011/65/EU) (2016/10/01)
