MEAN WELL

LDDS-300HW

Name: LDDS-300HW
Brand: MEAN WELL
Price: 12.37 USD
Availability: OutOfStock

Manufacturer Model Name

Availability: Out of stock

ℹ️ Lead time for quantities greater than shown, contact us

Quantity Prices

Quantity

Unit Price

$12.37

10+

$11.75

20+

$11.50

50+

$11.26

100+

$11.01

200+

$10.76

*Import tariff is included in the listed price. You pay exactly what you see—no surprise fees at checkout. Discounts are applied automatically based on the total quantity added to your cart.

Quick Specs

Output Voltage

45V

Rated Current

0.3A

Power Rating

45W

Waterproof

Non-waterproof

Dimensions

1.85 x 0.47 x 0.27 in

Weight

0.02 lbs

Características

Convertidor DC/DC reductor

Salida de corriente constante: 250mA a 1000mA

Amplio voltaje de entrada: 12~56VDC (48V típ.)

Amplio voltaje directo de LED de salida: 2~45VDC

Alta eficiencia hasta 96%

Filtro EMI incorporado, cumple con BS EN/EN55015

Regulación 3 en 1 y control remoto ON/OFF

Protecciones: Cortocircuito/Sobretemperatura/Sobrecorriente

Refrigeración por convección de aire libre

Tamaño compacto y totalmente encapsulado

Adecuado para conducir LED de iluminación

5 años de garantía

Especificación general

Precisión actual	±5% con entrada de 48VDC (o 24VDC)
Protección contra sobretemperatura	Tipo de protección: Apagado, se recupera automáticamente después de que la temperatura baja
Eficiencia	94%; 95%; 96% (típica)
Protección contra cortocircuitos	Regulado a la corriente de salida nominal
Temperatura de trabajo	-40°C a +55°C
CEM	Cumplimiento con EN55015 clase B, EN61000-4-2,3,4,6,8, EAC TP TC 020
Coeficiente de temperatura	±0.03% / °C
Dimensión (LxAnxAl) (mm)	47127mm o 1.85"0.47"0.28" pulgadas
Material de encapsulado	Epoxi (UL94-V0)

Environmental Documents

📄 E6) COC-REACH (2026/01/28) 📄 E9) CMRT (2025/04/25) 📄 E14) COC-ROHS 2 (2015/863/EU) (2024/10/04) 📄 REACH Certificate (PDF) (2020/12/03) 📄 ROHS Certificate (PDF) (2020/05/29) 📄 E12) COC-ROHS 2 (2011/65/EU) (2016/10/01)
