MEAN WELL

MDD01N-12N

Name: MDD01N-12N
Brand: MEAN WELL
Price: 6.65 USD
Availability: OutOfStock

Manufacturer Model Name

Availability: Out of stock

ℹ️ Lead time for quantities greater than shown, contact us

Quantity Prices

Quantity

Unit Price

$6.65

10+

$6.32

20+

$6.18

50+

$6.05

100+

$5.92

200+

$5.79

*Import tariff is included in the listed price. You pay exactly what you see—no surprise fees at checkout. Discounts are applied automatically based on the total quantity added to your cart.

Quick Specs

Output Voltage

12V

Rated Current

0.00A

Power Rating

Waterproof

Non-waterproof

Dimensions

0.77 x 0.27 x 0.45 in

Weight

0.00 lbs

Características:

Paquete SIP7 con configuración de pines estándar internacional
Rango de temperatura de funcionamiento de -40 a +95°C
Cumple con IEC/UL62368-1 (excepto 15Vo/±15Vo) y LVD IEC60601-1
Seguridad médica aprobada (1xMOPP/2xMOOP) según IEC60601-1
Baja corriente de fuga para el paciente <2μA
Protecciones: Cortocircuito (Continuo)
Aislamiento de E/S de alto voltaje de 6KVCC (aislamiento reforzado)
Bajo costo
3 años de garantía

Especificación general

Voltaje de entrada (Vcc)

5V (4.5 ~ 5.5V) | 12V (10.8 ~ 13.2V) | 24 (21.6 ~ 26.4V)

Voltaje de salida (Vcc)

1 Vo: 3.3V / 5V / 12V / 15V

2 Vo: ±5V / ±12V / ±15V

Protección contra sobrecarga

Apaga la salida cuando la potencia nominal ≥102%, se recupera automáticamente

Temperatura de funcionamiento

-40 ~ + 95°C

Protección contra cortocircuitos

Protección continua durante mucho tiempo

Certificado de seguridad

CB / UL / EAC / CE / UKCA (62368-1 + 60601-1)

Dimensiones (LxAnxAl)

19.7 x 7.1 x 11.5 mm

Environmental Documents

📄 E6) COC-REACH (2026/01/28) 📄 E9) CMRT (2025/04/25) 📄 E14) COC-ROHS 2 (2015/863/EU) (2024/10/04) 📄 REACH Certificate (PDF) (2020/12/03) 📄 ROHS Certificate (PDF) (2020/05/29) 📄 E12) COC-ROHS 2 (2011/65/EU) (2016/10/01)
