MEAN WELL

MDS01N-12

Name: MDS01N-12
Brand: MEAN WELL
Price: 5.61 USD
Availability: OutOfStock

Manufacturer Model Name

Availability: Out of stock

ℹ️ Lead time for quantities greater than shown, contact us

Quantity Prices

Quantity

Unit Price

$5.61

10+

$5.33

20+

$5.22

50+

$5.11

100+

$4.99

200+

$4.88

*Import tariff is included in the listed price. You pay exactly what you see—no surprise fees at checkout. Discounts are applied automatically based on the total quantity added to your cart.

Quick Specs

Output Voltage

12V

Rated Current

0.08A

Power Rating

Waterproof

Non-waterproof

Dimensions

0.76 x 0.49 x 0.38 in

Weight

0.00 lbs

Características

Paquete SI7 con pinout estándar internacional

Rango de temperatura de funcionamiento -40~+85℃

Amplio rango de entrada 4:1

Seguridad médica aprobada (2xMOPP) según IEC60601-1

Baja corriente de fuga al paciente <5µA

Protecciones: Cortocircuito (Continuo)/Sobrecarga

Aislamiento de E/S alto de 6KVCC o 4.2KVCA (Aislamiento reforzado)

Bajo costo

3 años de garantía

Especificaciones generales

Precisión de voltaje	±5.0%
Eficiencia	82%
Protección contra cortocircuitos	3 segundos máx.
Temperatura de trabajo	-40°C a +85°C
CEM	Cumplimiento de EN55011 clase A, EN61000-4-2,3,4,5,6,8
Coeficiente de temperatura	0.02% / ℃ (0 ~ 85℃)
Dimensión (LxAnxAl) (mm)	19.59.812.5mm

Environmental Documents

📄 E6) COC-REACH (2026/01/28) 📄 E9) CMRT (2025/04/25) 📄 E14) COC-ROHS 2 (2015/863/EU) (2024/10/04) 📄 REACH Certificate (PDF) (2020/12/03) 📄 ROHS Certificate (PDF) (2020/05/29) 📄 E12) COC-ROHS 2 (2011/65/EU) (2016/10/01)
