MEAN WELL

MDS15C-12

Name: MDS15C-12
Brand: MEAN WELL
Price: 35.89 USD
Availability: OutOfStock

Manufacturer Model Name

Availability: Out of stock

ℹ️ Lead time for quantities greater than shown, contact us

Quantity Prices

Quantity

Unit Price

$35.89

10+

$34.10

20+

$33.38

50+

$32.66

100+

$31.94

200+

$31.22

*Import tariff is included in the listed price. You pay exactly what you see—no surprise fees at checkout. Discounts are applied automatically based on the total quantity added to your cart.

Quick Specs

Output Voltage

12V

Rated Current

1.25A

Power Rating

15W

Waterproof

Non-waterproof

Dimensions

2 x 1 x 0.47 in

Weight

0.06 lbs

Características

Encapsulado DIP 2"x1" con asignación de pines estándar internacional

Amplio rango de entrada 2:1

Baja corriente de fuga del paciente <5µA

Amplio rango de temperatura de funcionamiento -40~+90℃

Seguridad médica aprobada (2xMOPP) según IEC60601-1

Protecciones: Cortocircuito (continuo)/Sobrecarga/Bajo voltaje de entrada

Alto aislamiento I/O de 4000 VCA (aislamiento reforzado)

3 años de garantía

Especificación general

Precisión de voltaje	±1%
Eficiencia	88%
Protección contra cortocircuitos	Continua, recuperación automática
Temperatura de trabajo	-40°C a +90°C
Coeficiente de temperatura	0,03% / ℃ (0 ~ 70℃)
Dimensiones (LxAnxAl) (mm)	50,825,412 mm (210,47 pulgadas)
