MEAN WELL

MDS20B-24

Name: MDS20B-24
Brand: MEAN WELL
Price: 44.01 USD
Availability: OutOfStock

Manufacturer Model Name

Availability: Out of stock

ℹ️ Lead time for quantities greater than shown, contact us

Quantity Prices

Quantity

Unit Price

$44.01

10+

$41.81

20+

$40.93

50+

$40.05

100+

$39.17

200+

$38.29

*Import tariff is included in the listed price. You pay exactly what you see—no surprise fees at checkout. Discounts are applied automatically based on the total quantity added to your cart.

Quick Specs

Output Voltage

24V

Rated Current

0.83A

Power Rating

20W

Waterproof

Non-waterproof

Dimensions

2 x 1 x 0.47 in

Weight

0.06 lbs

Características

Encapsulado DIP de 2"x1" con pinout estándar internacional

Amplio rango de entrada 2:1

Baja corriente de fuga para pacientes <5µA

Amplio rango de temperatura de funcionamiento de -40~+90℃

Seguridad médica aprobada (2xMOPP) según IEC60601-1

No requiere carga mínima

Protecciones: Cortocircuito (continuo)/Sobrecarga/Bajo voltaje de entrada

Alto aislamiento E/S de 4000 VCA (aislamiento reforzado)

3 años de garantía

Especificaciones generales

Precisión de voltaje	±1%
Eficiencia	90%
Protección contra cortocircuito	Continua, recuperación automática
Temperatura de trabajo	-40°C a +90°C
Coeficiente de temperatura	0.03% / ℃ (0 ~ 70℃)
Dimensiones (LxAnxAl) (mm)	50.825.412mm (210.47 pulgadas)
Embalaje	30g; 18 unidades/tubo, 432 unidades/24 tubos máx./caja

Environmental Documents

📄 E6) COC-REACH (2026/01/28) 📄 E9) CMRT (2025/04/25) 📄 E14) COC-ROHS 2 (2015/863/EU) (2024/10/04) 📄 REACH Certificate (PDF) (2020/12/03) 📄 ROHS Certificate (PDF) (2020/05/29) 📄 E12) COC-ROHS 2 (2011/65/EU) (2016/10/01)
