MEAN WELL

NLDD-350HW

Name: NLDD-350HW
Brand: MEAN WELL
Price: 8.02 USD
Availability: OutOfStock

Manufacturer Model Name

Availability: Out of stock

ℹ️ Lead time for quantities greater than shown, contact us

Quantity Prices

Quantity

Unit Price

$8.02

10+

$7.62

20+

$7.46

50+

$7.30

100+

$7.14

200+

$6.98

*Import tariff is included in the listed price. You pay exactly what you see—no surprise fees at checkout. Discounts are applied automatically based on the total quantity added to your cart.

Quick Specs

Output Voltage

52V

Rated Current

0.35A

Power Rating

60W

Waterproof

Non-waterproof

Dimensions

1.26 x 0.80 x 0.49 in

Weight

0.03 lbs

Características

Convertidor CC/CC reductor

Corriente de salida constante: 350mA a 1400mA

Amplio voltaje de entrada: 10~56VCC (59VCC máx.)

Amplio voltaje directo de salida para LED: 6~52VCC

Alta eficiencia de hasta 96%

Cumple con las regulaciones BS EN/EN61347 y BS EN/EN55015

Control PWM y ON/OFF remoto integrados

Protecciones: Cortocircuito/Sobretemperatura

Refrigeración por convección de aire libre

Totalmente encapsulado y tamaño compacto

Adecuado para conducir LED de iluminación

3 años de garantía

Especificación general

Precisión de la corriente	±5% a 48V
Protección contra sobretemperatura	Tipo de protección: Apagado, se recupera automáticamente después de que baja la temperatura
Eficiencia	96% a plena carga y entrada de 36VCC/48VCC
Protección contra cortocircuitos	Regulado a la corriente de salida nominal
Temperatura de trabajo	-40°C a +50°C
EMC	Conformidad con EN55015 clase B, EN61000-4-2,3,4,6,8, EAC TP TC 020
Coeficiente de temperatura	±0.03% / °C
Dimensiones (LxAnxAl) (mm)	32.120.512.5mm o 1.26"0.8"0.49" pulgadas
Material de encapsulado	Epoxi

Environmental Documents

📄 E6) COC-REACH (2026/01/28) 📄 E9) CMRT (2025/04/25) 📄 E14) COC-ROHS 2 (2015/863/EU) (2024/10/04) 📄 REACH Certificate (PDF) (2020/12/03) 📄 ROHS Certificate (PDF) (2020/05/29) 📄 E12) COC-ROHS 2 (2011/65/EU) (2016/10/01)
