MEAN WELL

RSDW20F-05

Name: RSDW20F-05
Brand: MEAN WELL
Price: 70.74 USD
Availability: OutOfStock

Manufacturer Model Name

Availability: Out of stock

ℹ️ Lead time for quantities greater than shown, contact us

Quantity Prices

Quantity

Unit Price

$70.74

10+

$67.20

20+

$65.79

50+

$64.37

100+

$62.96

200+

$61.54

*Import tariff is included in the listed price. You pay exactly what you see—no surprise fees at checkout. Discounts are applied automatically based on the total quantity added to your cart.

Quick Specs

Output Voltage

Rated Current

Power Rating

20W

Waterproof

Non-waterproof

Dimensions

2 x 1 x 0.40 in

Weight

0.07 lbs

Características

Cumplimiento de la norma ferroviaria EN50155

Encapsulado DIP de 2" x 1" con pinout estándar

Amplio rango de entrada 4:1

Amplio rango de temperatura de funcionamiento -40~+85°C

No se requiere carga mínima

Completamente encapsulado

Protecciones: Cortocircuito (Continuo)/Sobrecarga/Sobretensión/Baja tensión de entrada

Aislamiento E/S de 1,5KVDC, 3KVDC según modelos

Control remoto ON/OFF

3 años de garantía

Especificación general

Precisión de tensión	±1.5%
Protección contra sobrecarga	110~160% de la potencia de salida nominal
Eficiencia	90%
Protección contra cortocircuitos	Continua, recuperación automática
Temperatura de trabajo	-40°C a +85°C
CEM	Cumplimiento de EN55032 clase A, EN61000-4-2,3,4,5,6
Coeficiente de temperatura	0.03% / ℃ (0 ~ 71℃)
Dimensiones (LxAnxAl) (mm)	50.825.410.2mm
Material de encapsulado	Plástico negro no conductivo

Environmental Documents

📄 E6) COC-REACH (2026/01/28) 📄 E9) CMRT (2025/04/25) 📄 E14) COC-ROHS 2 (2015/863/EU) (2024/10/04) 📄 REACH Certificate (PDF) (2020/12/03) 📄 ROHS Certificate (PDF) (2020/05/29) 📄 E12) COC-ROHS 2 (2011/65/EU) (2016/10/01)
