SPB09B-12 MEAN WELL Power Supply | HTD Electronics
MEAN WELL

SPB09B-12

Manufacturer Model Name
Availability: Out of stock

Request a Backorder

Submit your request and we will confirm lead time.

SPB09B-12
Quantity Prices (MXN)
Quantity
Unit Price (MXN)
1+
$ 251.64 MXN
10+
$ 239.06 MXN
20+
$ 234.03 MXN
50+
$ 228.99 MXN
100+
$ 223.96 MXN
200+
$ 218.93 MXN
All prices are displayed in MXN. *Import tariff is included in the listed price. You pay exactly what you see—no surprise fees at checkout. Discounts are applied automatically based on the total quantity added to your cart.
Quick Specs
Input Voltage
18V~36V
Output Voltage
12V
Rated Current
0.75A
Power Rating
9W
Waterproof
Non-waterproof
Dimensions & Weight
0.98 x 0.44 x 0.37 in0.01 lbs

Features

SIP8 package with industry-standard pinout
2:1 wide input range
Wide operating temperature range -40~+90°C
No minimum load required
High efficiency up to 89%
Protection: Short circuit(continuous)/Overload/Input under voltage
1.5KVDC I/O isolation

Remote ON/OFF control

9V model available(optional)

3 years warranty

General Specification

Voltage accuracy ±1.5%
Vibration 10 ~ 500Hz, 2G 10min./1 cycle, the period for 60min. each along X, Y, and Z axes
Cooling Free-air convection
Short circuit protection Continuous, auto-recovery
Working temperature -40°C to +90°C
EMC Compliance to EN55032 Class A, EN61000-4-2,3,4,5,6,8
Temp. Coefficient 0.03% / ℃ (0 ~ 70℃)
Dimension (LxWxH) (mm) 24*9.6*11.2mm
Potting material UL 94V-0 rated

Similar Models

Same product family and output voltage, with the closest available power ratings.

Environmental Documents
📄 E6) COC-REACH (2026/01/28) 📄 E9) CMRT (2025/04/25) 📄 E14) COC-ROHS 2 (2015/863/EU) (2024/10/04) 📄 REACH Certificate (PDF) (2020/12/03) 📄 ROHS Certificate (PDF) (2020/05/29) 📄 E12) COC-ROHS 2 (2011/65/EU) (2016/10/01)
