MEAN WELL

PLP-45-24

Name: PLP-45-24
Brand: MEAN WELL
Price: 38.96 USD
Availability: OutOfStock

Manufacturer Model Name

Availability: Out of stock

ℹ️ Lead time for quantities greater than shown, contact us

Quantity Prices

Quantity

Unit Price

$38.96

10+

$37.01

20+

$36.23

50+

$35.45

100+

$34.67

200+

$33.90

*Import tariff is included in the listed price. You pay exactly what you see—no surprise fees at checkout. Discounts are applied automatically based on the total quantity added to your cart.

Quick Specs

Output Voltage

24V

Rated Current

1.9A

Power Rating

45W

Waterproof

Non-waterproof

Dimensions

4 x 2 x 1.16 in

Weight

0.35 lbs

Características

Entrada de CA universal/rango completo

Función PFC activa incorporada

Protecciones: Cortocircuito / Sobrecarga / Sobretensión

Enfriamiento por convección natural

Unidad de potencia Clase 2

Nivel de corriente de salida ajustable

100% de prueba de quemado a plena carga

Alta fiabilidad

Adecuado para aplicaciones integradas de iluminación LED

2 años de garantía

Especificaciones generales

Rango de voltaje de entrada de CA	90~264 V CA 127~370 V CC
Corriente de irrupción de CA (máx.)	Arranque en frío, 25 A a 230 V CA
Rango de ajuste de CC	75%~100% de la corriente nominal
Protección contra sobrecorriente	100%~110%
Protección contra sobretensión	hasta el 150% de la tensión nominal
Protección contra cortocircuitos	Modo intermitente
Tensión de aislamiento	E/S - S/P: 3.75 kV CA, E/S - FG: 2 kV CA, S/P-FG: 0.5 kV CA
Temperatura de funcionamiento	-30~+70°C
Normas de seguridad	BS EN/EN61347-1, BS EN/EN61347-2-13
Normas EMC	EN55015, EN61000-3-2 Clase C, EN61000-4-2,3,4,5,6,8,11,
Conexión	JST B3P/B2P
Dimensiones (LxAnxAl)	101.6x50.8x26.6
Embalaje	108 unidades/13 kg

Environmental Documents

📄 E6) COC-REACH (2026/01/28) 📄 E9) CMRT (2025/04/25) 📄 E14) COC-ROHS 2 (2015/863/EU) (2024/10/04) 📄 REACH Certificate (PDF) (2020/12/03) 📄 ROHS Certificate (PDF) (2020/05/29) 📄 E12) COC-ROHS 2 (2011/65/EU) (2016/10/01)
