MEAN WELL

RSDW08F-03

Name: RSDW08F-03
Brand: MEAN WELL
Price: 20.03 USD
Availability: OutOfStock

Manufacturer Model Name

Availability: Out of stock

ℹ️ Lead time for quantities greater than shown, contact us

Quantity Prices

Quantity

Unit Price

$20.03

10+

$19.03

20+

$18.63

50+

$18.23

100+

$17.83

200+

$17.43

*Import tariff is included in the listed price. You pay exactly what you see—no surprise fees at checkout. Discounts are applied automatically based on the total quantity added to your cart.

Quick Specs

Output Voltage

3.3V

Rated Current

Power Rating

Waterproof

Non-waterproof

Dimensions

1.25 x 0.79 x 0.40 in

Weight

0.04 lbs

Características

Cumple con la norma ferroviaria EN50155

Encapsulado DIP 24 con pinout estándar

Amplio rango de entrada 4:1

Amplio rango de temperatura de funcionamiento -40~+85°C

No requiere carga mínima

Totalmente encapsulado

Protecciones: Cortocircuito (continuo)/Sobrecarga/Sobretensión/Baja tensión de entrada

Aislamiento E/S de 1.5KVCC

Control remoto de ENCENDIDO/APAGADO

3 años de garantía

Especificación general

Precisión de voltaje	±1.5%
Protección contra sobrecarga	120~180% de la potencia de salida nominal
Eficiencia	86%
Protección contra cortocircuito	Continua, recuperación automática
Temperatura de funcionamiento	-40°C a +85°C
CEM	Conformidad con EN55032 clase A, EN61000-4-2,3,4,5,6
Coef. de temperatura	0.03% / ℃ (0 ~ 71℃)
Dimensiones (LxAnxAl) (mm)	31.820.310.2mm
Material de encapsulado	Plástico negro no conductor

Environmental Documents

📄 E6) COC-REACH (2026/01/28) 📄 E9) CMRT (2025/04/25) 📄 E14) COC-ROHS 2 (2015/863/EU) (2024/10/04) 📄 REACH Certificate (PDF) (2020/12/03) 📄 ROHS Certificate (PDF) (2020/05/29) 📄 E12) COC-ROHS 2 (2011/65/EU) (2016/10/01)
