MEAN WELL

GE18I48-P1J

Name: GE18I48-P1J
Brand: MEAN WELL
Price: 21.75 USD
Availability: OutOfStock

Manufacturer Model Name

Availability: Out of stock

ℹ️ Lead time for quantities greater than shown, contact us

Quantity Prices

Quantity

Unit Price

$21.75

10+

$20.66

20+

$20.23

50+

$19.79

100+

$19.36

200+

$18.92

*Import tariff is included in the listed price. You pay exactly what you see—no surprise fees at checkout. Discounts are applied automatically based on the total quantity added to your cart.

Quick Specs

Output Voltage

48V

Rated Current

0.37A

Power Rating

18W

Waterproof

Non-waterproof

Dimensions

3.18 x 1.69 x 1.59 in

Weight

0.29 lbs

Datasheet (PDF)

Open PDF

If the PDF doesn’t load here, click “Open PDF”.

Features

Interchangeable AC plugs (plug kit sold seperately)

Universal AC input / Full range

Protections: Short circuit / Overload / Over voltage

No load power consumption <0.3W

ErP step 2 compliant (Level V)

Meet EISA 2007 (Energy Independence and Security Act)

Class II power (without earth pin)

Fully enclosed plastic case

LED indicator for power on

Pass LPS

Approvals: UL / CUL / TUV / CCC / RCM / CB / FCC / CE

2 years warranty

General Specification

AC input voltage range	90~264VAC / 0.7A
AC inrush current (max.)	Cold start, 40A at 100VAC; 80A at 230VAC
Setup, rise, hold up time	4000ms, 100ms, 30ms at 230VAC input
Overload protection	Hiccup mode, auto-recovery
Over voltage protection	115%~135% rated output voltage
Withstand voltage	I/P-O/P:4242VDC, 1 minute
Working temperature	-10~+50°C (refer to output derating curve)
Safety standards	UL60950-1, CSA22.2, EN60950-1, GB4943, AS/NZS 60950.1 approved
EMC standards	EN55022 class B, EN61000-3-2,3, EN61000-4-2,3,4,5,6,8,11, FCC part15 class B, GB9254
Length of output cable	150cm of AWM2468, 18AWG
Dimension (LxWxH)	70.7x 40x 38.8 mm
Standard DC plug	P1J: 2.1ID x 5.5OD x 11L, tuning fork type

Environmental Documents

📄 E6) COC-REACH (2026/01/28) 📄 E9) CMRT (2025/04/25) 📄 E14) COC-ROHS 2 (2015/863/EU) (2024/10/04) 📄 REACH Certificate (PDF) (2020/12/03) 📄 ROHS Certificate (PDF) (2020/05/29) 📄 E12) COC-ROHS 2 (2011/65/EU) (2016/10/01)
